Streetlight Twin 0,6/1kV AL PVC
XLPE insulated and PVC sheathed power cable with Al conductors, rated voltage 0,6/1 kV
Application
Power distribution cable designed for roadway and street lighting, entry point installation, and other general outdoor applications (UV-resistant). Each phase is individually insulated and sheathed. The cable is suitable for direct burial in soil and may also be installed in water, provided it is not subjected to additional mechanical stress. When laying at a lower temperatures than 0 °C degrees Celsius, care must be taken to avoid damaging the outer sheath. It is especially important to prevent any mechanical impact at temperatures below 0 °C. For installations at temperatures below -10 °C, the cable must be preheated prior to laying. If the cable is cut and not installed
immediately, each phases must be properly sealed to prevent moisture and water penetration.
Expected life time: 50 years provided proper installation, load and ambient temperature.
CENELEC code: N01XV-AR
Construction
Conductors: Al, class 2 according to EN 60228
Insulation: XLPE compound
Outer Sheath: PVC compound, UV resistant
Technical characteristics
Rated voltage (Uo/U): 0,6/1 kV
Test voltage: 4 kV AC 50 Hz, 5 min.
Min. temp. for cable laying: -10°C
Min. outer temp., fixed installation: -40°C
Max. outer temp., fixed installation: 70°CMax.
conductor operating temperature: 90°C
Max. short-circuit temperature: 250°C
Min. bending radius: 6D, D = outer diameter
Country: Estonia, Finland, Norway, Sweden
Industry: Building & Construction, Transmission, Distribution & Power Networks
Standard: EN 60332-1-2, HD 603-5J, HD 604 5D, SS 424 14 18
Type: Industrial Cable, Power Network & Local Distribution Cable
